Wet mills cool the cut with water, which is how glass ceramic and titanium are milled. This page lines up every wet-only milling unit we stock, from every brand, so you can compare them before you ask for pricing.
The 7 wet mills compared below
DEPRAG, UP3D, BSM, YUCERA, XTcera
Every specification below comes from the manufacturer or our store listing for that exact model. A field that nobody publishes reads “Not published”, never a guess. Click a photo to open the machine on the store. Pricing is configuration-dependent: call or request a quote and we send a written figure the same day.
| Characteristic | DEPRAGW4 | UP3DP42 Plus | BSM420W | YUCERAYRC-6X | YUCERAYRC-7S | YUCERAYRC-8S | XTceraX-Mill 630 |
|---|---|---|---|---|---|---|---|
Machine | |||||||
| USDD SKU | 485195 | 473290 | 496270 | 496294 | 496295 | 496296 | 486984 |
| Processing mode | Wet | Wet | Wet | Wet | Wet | Wet | Wet |
| Axes | 4-axis | 4-axis (A-axis 360°) | 4-axis (simultaneous) | 5-axis | 4-axis | 5-axis | 5-axis (A 360°, B +/-30°) |
| Disc changer | No disc changer | Not listed | Not published | No disc (manufacturer lists 0 disc, 6+2 blocks) | Not published | Single disc (manufacturer lists 1 disc, 5+3 blocks) | No: manual blank/disc loading, no automatic disc changer |
| Cabinet / table | Included | Not published | Not published | Not published | Not published | Not published | Floor-standing with integrated cabinet base |
| Holder type | Pre-mill abutment holder / block holder | Blocks up to 40x20x20 mm; optional TK abutment holders (K-GE: DESS, Geo CMFit, Dentium, Osstem, Arum; TK-ME: MEDENTiKA) for custom abutments | Holding quantity: 10 units premill, 3 units glass ceramic (square blocks) | Holds up to 8 blanks (6+2 blocks), up to 6 milled at the same time (manufacturer) | Not published | Standard C-clamp (suitable for lithium disilicate blocks and pre-milled); 2 fixture types (manufacturer) | Not published |
| 98 mm disc / Cerec mandrel | Not published | Not published | Not published | Not published | Not published | Not published | Not published |
| C-clamp option | Not listed | Not published | Not published | Not published | Not published | Yes | Not published |
Spindle, tools and accuracy | |||||||
| Spindle power | 2.5 kW | Peak 800 W, continuous (S1) 450 W | 1800KW as printed on the manufacturer page (unit is evidently a typo) | Peak 1500 W, nominal 800 W (manufacturer) | Not published | 1.8 kW | 2.5 kW |
| Spindle cooling | Water-cooled | Not published | Water-cooled | Not published | Not published | Not published | Water-cooled |
| Spindle speed | 60,000 rpm | 60,000 rpm (max) | Up to 60,000 rpm | Up to 60,000 rpm | 60,000 rpm (store) | 0-60,000 rpm | 60,000 rpm |
| Collet / shank | Ø6 mm | 4.0 mm tool holding | Tools are 6 mm shank (phi 6 mm metal and glass ceramic burs per manufacturer) | Not published | Not published | Not published | Not published |
| Accuracy | 5 µm repeat positioning, up to 0.01 mm overall | Not published | Not published | Not published | Not published | +/-0.01 mm (store) | 2 um repeated positioning accuracy |
| Tool magazine | 12 tools, automatic change | 6-tool magazine with length measurement and breakage monitoring | Automatic tool changer with haptic detection and breakage monitoring; 6 built-in burs (store) | 10 (manufacturer and store agree) | 4 (store) | 16 automatic tool magazines (manufacturer); store and price list say 21 | 24 burs, automatic tool changer with real-time tool life and damage monitoring |
| Tool sourcing (manufacturer-required or open OEM) | Not published | UP3D standard bur set included (6 burs for glass ceramic); upgraded UP3D-designed burs and optional additional burs from UP3D. Third-party tool acceptance not published | Manufacturer lists specific burs: metal phi6x3, 2, 1 mm; glass ceramic phi6x2.5, 1, 0.6 mm. Whether third-party tools are accepted is not published | Not published | Not published | Not published | Not published |
Materials milled | |||||||
| Zirconia | Not listed | Not listed | Not listed | Not published | Not listed | Not listed | Not listed |
| Glass ceramic / glass blocks | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| PMMA | Yes | Yes | Not listed | Yes | Yes | Yes | Yes |
| PEEK | Yes | Not listed | Not listed | Not listed | Not listed | Not listed | Not listed |
| Wax | Not listed | Not listed | Not listed | Not listed | Not listed | Not listed | Yes |
| Composite resin | Yes | Yes | Yes | Yes | Not listed | Not listed | Not listed |
| Pre-milled blanks | Yes | Not published | Yes | Not published | Not listed | Yes | Yes |
| Titanium | Not listed | Yes | Yes | Yes | Yes | Yes | Yes |
| Titanium bars (implant bar) | Not listed | Not published | Not published | Not published | Not listed | Not published | Not published |
| Chrome cobalt (CoCr) | Not listed | Not listed | Yes | Not listed | Not listed | Not published | Not listed |
Room and utilities | |||||||
| Water cooling | Water cooling system + 10 L tank included | Wet milling. Manufacturer: pure water milling, no additives required. Store: coolant is water or UP3D P42 special milling liquid per model requirement (SKU 486034) | Water cooling spindle; wet milling (tank size not published) | Automatic circulating water system with integrated water level monitoring (manufacturer) | Not published | 25 L water tank, double-layer filtration system (manufacturer) | Integrated water cooling system with coolant tank and pump supplied |
| Air requirements | > 0.5 MPa (72.5 psi), > 90 L/min | No compressor required (manufacturer P42 PLUS page) | Air pressure above 0.65 MPa (manufacturer) | 6.0-7.5 bar, oil-free, without water (manufacturer) | Not published | 4.5-7.5 bar, about 120 L/min compressed air (manufacturer) | Compressed air at least 0.6 MPa; external compressor required, not included |
| Dust extraction / vacuum | Not required, wet only | Not published | Not published | Not published | Not published | Not published | Not published |
| Power supply | 220V / 3.2 kW (110V to 220V transformer: SKU 485203) | AC 100-240 V, 50-60 Hz. Store lists 110 V | 220V / 3.7KW | 220-230 V, 1.5 kW (manufacturer); store: 220 V | 220 V (store) | 220-230 V AC 50/60 Hz, 2.5 kW (manufacturer); store: 220 V | AC 220 V |
| Dimensions / weight | 523 x 718 x 820 mm, 130 kg | 564 x 402 x 564 mm (W/D/H), 80 kg | 570 x 800 x 1650 mm (W/D/H), 300 kg | Manufacturer: 535 x 655 x 720 mm with flap and drawer open, footprint 480 x 580 mm, 170 kg. Store: 650 x 530 x 775 mm, 160 kg | 530 x 390 x 545 mm (20.87 x 15.35 x 21.46 in), 88 kg (store) | Manufacturer: 595 x 760 x 1650 mm with flap and drawer open, 360 kg. Store: 760 x 600 x 1625 mm, weight not stated | 800 x 650 x 1750 mm (W x D x H), 450 kg net, about 650 kg crated |
| Installation | Not published | Installation, commissioning and operator onboarding from US Dental Depot (store) | Not published | Not published | Not published | Optional dry and wet intelligent switching module, vacuum cleaner, air pump available (manufacturer) | Floor-standing, crated, LTL freight with liftgate recommended; 220 V circuit by electrician; compressor not included; crated weight about 650 kg |
Software | |||||||
| CAM options | Not published | UPCAM (standard version included; Advanced optional) and Soreal automatic CAM; UPCNC integrated; store lists UPCAM nesting SKU 473694 / 484665 | Smart CAM nesting strategy, open processing system, integrated PC with 9.7 inch touch screen | Not published | Not published | Not published | Not published |
Throughput, warranty and price | |||||||
| Time per crown | Not published | Not published | Titanium full-contour single crown about 32 min; glass ceramic full-contour anterior crown about 20 min | Full crown < 15 min, 3-unit bridge < 30 min (manufacturer) | Not published | Not published | Published cycle times: wax 3 min, glass ceramic 17 min, premilled abutment 25 min |
| Warranty | 1 year, parts only | UP3D: 1 year, parts and labor | Term not published by Besmile. Parts warranty, term confirmed in writing | Not published | Not published | Not published | Limited manufacturer warranty, term not published |
| Price | Call for Price: 954-874-6325check live price | Call for Price: 954-874-6325check live price | Call for Price: 954-874-6325check live price | Call for Price: 954-874-6325check live price | Call for Price: 954-874-6325check live price | Call for Price: 954-874-6325check live price | Call for Price: 954-874-6325check live price |
On “time per crown”: manufacturers do not publish a comparable per-crown cycle time, and we will not invent one. Real cycle time depends on the material, the disc, the CAM strategy, the tool set and the margin detail. Tell us what you mill and we will give you a realistic figure from labs running the same work. Call 954-874-6325.
What the processing mode means in practice, before you compare individual models.
These models list titanium among the materials they mill.
UP3D P42 Plus, BSM 420W, YUCERA YRC-6X, YUCERA YRC-7S, YUCERA YRC-8S, XTcera X-Mill 630
These models state that no compressed air is needed.
UP3D P42 Plus
These models list 5-axis machining, which reaches undercuts and abutment geometries that 4-axis cannot.
YUCERA YRC-6X, YUCERA YRC-8S, XTcera X-Mill 630
Send us your materials, case volume and room details. We recommend the right model and quote it in writing the same day.
Where the store listing, the manufacturer site or a brochure disagree, we show the conflict instead of picking a number silently. Confirm anything critical with us in writing before you order.
Milling machine pricing depends on configuration: voltage, cabinet, cooling, dust extraction and software all change the number. Rather than publish a figure that will not match your build, we quote in writing. Request a quote or call 954-874-6325 and you get a real price the same day.
DEPRAG, UP3D, BSM, YUCERA, XTcera. Every wet milling unit in the US Dental Depot CAD/CAM milling-units catalog is in the table, including voltage and open-box variants where they exist.
By the processing mode and materials the manufacturer or our store listing publishes. Where the store listing and the manufacturer disagree, the Data Notes section below the table says so, model by model.
Yes. Delivery, installation and operator training are arranged by US Dental Depot and quoted with the machine, so the full cost is on the quote before you commit. Call 954-874-6325.
It differs by brand and model. The Power supply row shows what each manufacturer or store listing publishes. Confirm your available supply with us before ordering.
Tell us the materials you mill and the volume you run. We will come back with the right model and a written price the same day.
