Description

AJ16 BEYOND 300

■ OTP Operatory Package without cuspidor

PRODUCT DESCRIPTION

■ AJ16 Luxury hydraulic chair, with 3 programmable positions,

■ Double articulating headrest, Swing up/down armrest,

■ Wide backrest, upgraded fiber leather, Cast iron chair frame,

■ Cast alurminiun backrest stand, Cast aluminum base,

■ 60 degrees seat rotation, chair safety switch,

■ One touchpad, Foot control

STANDARD FEATURES

■ Beyond luxury dentist's control head, Standard touchpad,

■ Cast aluminum delivery head base, double pivot delivery head, with 3 auto HP control,

■ lndividual water coolant controls, Master handpiece air coolant adjustment,

■ Asepsis handpiece tubing.

■ Master on/off switch, 1 doctor syringe, Wet/Dry foot control,

■ Stainless steel tray with non-slip pad, Flex arm air brake switch,

■ Beyond 300 Post mounted utility (PMU) with silver side box,

■ City water/bottled system, Water outlet and air QD, Swing assistant tray with touchpad,

■ Solids collector, 2 HVE, 1SE, 1 syringe, Alumium base

■ Junction box with air/water filters, regulators, master shut-off valves, 5 ft umbilical

■ Post mount LED light with sensor control, 3 level intensity adjustment

PACKAGE INCLUDES

PART NUMBER

A091602

A0723002

A0502550

A0730020

A0602670

A11203

DESCRIPTION

A J 1 6 Hydraulic Chair
A J 1 6 wide backrest hydraulic chair with 3 programmable postions and fiber leather

Beyond-300 delivery system

Beyond Post mount Dentist's Control
Beyond luxury dentist's control head, Cast aluminium delivery head base, double pivot delivery head,
with 3 auto H.P.control, 1 doctor syringe,
Wet/Dry foot control, Stainless steel tray, Rigid arm and Flex arm

Beyond-300 Post Mounted Utility (PMU)
Beyond-300 Post mounted utility (PMU) with silver side box,
City water/bottled system, Swing assistant tray with touchpad, 2 HVE,1SE,1 syringe,
Alumium base Junction box with valves

Post mount Amber II LED light
Post mount touchless sensor Amber II LED light with 30" light post

Chair adapter C

PACKING DIMENSIONS (L*W*H)

Chair

Upholstery

Beyond Dentist's Control

PMU

Dental Light

47.6*30.5*31.3"

50.4*25*8.9"

30.8*23.1*14.1"

37.4*25.7*16.1"
