High‑speed German spindle
Up to 60,000 rpm with automatic tool change for continuous, accurate dry milling.
UP3D P55D — Air‑Free 5‑Axis Dry Milling
Plug‑and‑mill install, no compressor required. 60,000 rpm German spindle, 13‑tool ATC, servo precision, and MillMind remote monitoring.
- No Compressor
- 60,000 rpm
- 13‑Tool ATC
- 5‑Axis Servo
- Dust‑Proof Design
Materials: Zirconia, PMMA, Wax, PEEK, Composite/Hybrid, Soft CoCr (dry). Discs Ø98.5 mm (H 10–30 mm); blocks up to 40×20×20 mm.
Key Features
Dust‑proof, low‑maintenance
Fully sealed silicone dust‑proofing helps protect components and reduce service time.
Versatile materials & workflows
Disc & block workflows for zirconia, wax, PMMA, PEEK, composites, and soft CoCr.
MillMind remote
Monitor tools, receive reminders, and supervise production from PC or mobile.
Business Advantages
- ✓ No compressor required: faster installs and lower facility costs.
- ✓ 24/7 readiness: servo drive + 13‑tool magazine support long, unattended runs.
- ✓ Lab‑friendly footprint: compact size with a generous working chamber.
- ✓ Lower maintenance load: integrated dust‑proofing and streamlined service steps.
Installation Requirements
Power
- Voltage: 100–130 VAC or 200–235 VAC (selectable), 50–60 Hz
- Power draw: Machine max ~1.0 kW; spindle max ~0.8 kW
Air & Extraction
- Compressor: Not required (air‑free design)
- Dust extraction: M‑class filter; flow ≥ 2,500 L/min
Connectivity
- Wi‑Fi, USB, or Ethernet
- MillMind / UPCAM / UPCNC workflow
Environment & Size
- Operating temp: 10–35 °C; RH: < 80% (non‑condensing)
- Dimensions (W×D×H): 442×560×704 mm
- Weight: 106 kg
Always verify utilities and site readiness with a US Dental Depot specialist prior to delivery.
Request More Information
Have questions about fit, lead times, financing, or training? Send your details and our team will contact you.
