UP3D P53 — Smart 5‑Axis Dry Milling Machine

40,000 rpm spindle, 11‑tool ATC, BK‑1 quick clamp for disc ↔ block swaps, 90° vertical micro‑carving, and one‑click calibration with MillMind remote oversight.

Materials: Zirconia • PMMA • Wax • PEEK • Soft CoCr
Schedule a live demo Buy on US Dental Depot Request more info
5‑Axis Dry 40k rpm • 11‑tool ATC
BK‑1 Clamp Rapid disc/block changes
90° Micro‑carving 0.3 mm detail tools
Smart Control One‑click calibration • MillMind
UP3D P53 Front View

Built for daily lab production — fast, precise, low‑maintenance

P53 seals critical motion rails behind a dust‑proof slide, pairs a 40,000 rpm spindle with precise 5‑axis kinematics, and uses a BK‑1 clamp to switch between discs and blocks in seconds. One‑click smart calibration and MillMind remote reminders keep jobs moving without babysitting.

Dust‑proof slide
Low maintenance
  • Sealed slide protects mechanics from zirconia/PMMA dust
  • Stable accuracy with less cleaning downtime
BK‑1 clamp
Versatile
  • Disc & block workflows on one platform
  • Faster changeovers = more throughput
One‑click calibration & tool station
Precision
  • One‑click calibration keeps tolerances tight
  • 0.3 mm tools for fine occlusal detail & margins

Watch the P53 in action

Short demos & feature explainers you can share with decision‑makers.

How to operate P53
How to operate P53
P53 overview video
P53 — overview & features
90° milling demo
90° vertical milling (demo)
Customer feedback
Customer feedback
Book a live demo Buy now

Key features

  • 5‑axis simultaneous dry milling (discs & blocks)
  • 40,000 rpm spindle; 11‑tool automatic changer
  • BK‑1 quick‑change clamp; one‑click calibration
  • 90° vertical micro‑carving with 0.3 mm tools
  • MillMind remote control & tool‑life monitoring
  • Materials: Zirconia, PMMA, Wax, PEEK, soft CoCr
  • CAM: UPCAM (official) • MillBox compatible
  • Data: Ethernet (UPCNC control; remote status)
  • Disc 98/98.5 mm (10–30 mm); blocks up to 40×20×20 mm
  • Resume‑after‑breakpoint + multi‑machine control
  • Dust‑proof slide extends service life and stability
  • Compact footprint for lab benches
  • Clear LED progress strip for at‑a‑glance status
  • Designed for daily production and easy upkeep

Advantages for your lab

Throughput
  • Rapid disc/block changeovers keep the spindle cutting
  • High feed rates and optimized CAM strategies
Consistency
  • One‑click calibration maintains accuracy between jobs
  • Tool‑life tracking reduces remakes and stoppages
Low upkeep
  • Dust‑proof slide design cuts cleaning time
  • Straightforward daily maintenance routines

Requirements & Technical Specs

Electrical & Pneumatics

Voltage
AC 100–240 V, 50–60 Hz
Max Power
~1.1 kW
Compressed Air
ATC: >0.5 MPa • Spindle cooling: 0.15–0.20 MPa
Dust Extraction
M‑class filter; ~2,500–2,600 L/min recommended
Data
Ethernet (UPCNC control); Wi‑Fi/USB supported

Machine & Performance

Axes / Mode
5‑axis simultaneous / Dry
Spindle
40,000 rpm; Φ4.0 mm collet
Tool Magazine
11 tools (auto change)
Travel
X/Y/Z: 167/200/90 mm • A: ±30° • B: ±360°
Size / Weight
443.5 × 718 × 628.5 mm • 87 kg

Computer (UPCAM / UPCNC)

OS
Windows 10/11 (64‑bit, Professional recommended)
CPU
Intel® i7‑7700 or higher
RAM
16 GB or more
GPU
NVIDIA® GTX 1050 or better
Storage
SSD for OS + ≥300 GB free on secondary drive

Workholding & Materials

Discs
98 mm (10–30 mm height)
Blocks
Up to 40 × 20 × 20 mm
Materials
Zirconia, PMMA, Wax, PEEK, soft CoCr
CAM
UPCAM (official); MillBox compatible
